| Form Factor (Midi, Micro, Mini ITX, Full) | Mid Tower ATX EATX | |
| Chassis | SPCC 0.5mm, Black painting interior | |
| PSU Form Factor | Bottom/ATX | |
| M/B Form Factor | ATX/M-ATX/Mini-ITX | |
| Front Panel | ABS | |
| Top Panel | Mesh for better heat disspation with easily accessible dust filter | |
| Branding | Box | By OEM |
| Unit | 1 | |
| Side Panel | Left | Tempered glass |
| Right | Metal | |
| External Drive Bay(s) | 5.25" (ODD) | *0 |
| 3.5" | *0 | |
| Internal Drive Bay(s) | 3.5" (HDD) | *2 |
| 2.5" (SSD) | *2 | |
| I/O SPEC | Buttons | *2 |
| USB2.0 Port(s) | *2 | |
| USB3.0 Port(s) | *1( optional) | |
| USB3.1 Port(s) | *0 | |
| HD Audio Support | *1 | |
| Card Reader (Support) | *0 | |
| Fan Controller | *1 （V1.4） | |
| RGB Controller | *0 | |
| Controller max. fans | *8 | |
| Cooling Fan Support | Front | 3x120mm,2x140mm (optional) |
| Top | 2x120mm ,2x140mm (optional) | |
| Rear | 1x120mm (optional) | |
| Bottom | None | |
| Left Side | 1x COC Turbo fan | |
| PSU Cover | *2 | |
| Water Cooling Support(Radiator Size) | Front | 120/140/240/280mm/360mm(Support) |
| Top | 0 | |
| Rear | 120mm(Support) | |
| Dust filter | Bottom and top cover with dust filter | |
| Slots | *7 | |
| Carton & Logo | GAMEMAX | |
| Dimensions | Chassis | (L)360*(W)210*(H)440mm |
| Full Case (inc Fascia) | (L)408*(W)210*(H)460mm | |
| Carton | (L)506*(W)266*(H)465mm | |
| VGA Card Length | 330 mm | |
| CPU Cooler Height | 170 mm | |
| Cable Management Depth | 22 mm | |
